[Properties]
1. High hardness, the Rockwell hardness is hra80-90, the hardness is second only to diamond.
2. The wear resistance is 266 times of manganese steel and 171.5 times of high chromium cast iron.
3. It is light in weight and its density is 3.6g/cm3, which is only half of steel. It can greatly reduce the equipment load.
4. Convenient construction
[Application]
It is used for coal conveying, material conveying system, pulverizing system, ash discharging and dedusting equipment in thermal power, iron and steel, smelting, machinery, coal, mining, chemical industry, cement, port and wharf industries etc
| Quantity: | |
|---|---|
[Properties]
1. High hardness, the Rockwell hardness is hra80-90, the hardness is second only to diamond.
2. The wear resistance is 266 times of manganese steel and 171.5 times of high chromium cast iron.
3. It is light in weight and its density is 3.6g/cm3, which is only half of steel. It can greatly reduce the equipment load.
4. Convenient construction
[Application]
It is used for coal conveying, material conveying system, pulverizing system, ash discharging and dedusting equipment in thermal power, iron and steel, smelting, machinery, coal, mining, chemical industry, cement, port and wharf industries etc.
[Chemical composition and physical properties]
Series | T36 | TG365 |
AL2O3(%) | 92±0.5 | 95±0.5 |
Bending strength (Mpa) | ≥220 | ≥250 |
Compressive strength (Mpa) | ≥1050 | ≥1300 |
Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 |
Rockwell hardness (HRA) | ≥82 | ≥85 |
Wear volume (cm3) | ≤0.25 | ≤0.2 |
Bulk density (g/cm3) | ≥3.6 | ≥3.65 |
[Specification Available]
Length*Width | Height | Note |
10*10 | 3-10 | paste |
17.5*17.5 | 3-10 | paste |
20*20 | 4-10 | paste |
25*25 | 4-10 | paste |
[Properties]
1. High hardness, the Rockwell hardness is hra80-90, the hardness is second only to diamond.
2. The wear resistance is 266 times of manganese steel and 171.5 times of high chromium cast iron.
3. It is light in weight and its density is 3.6g/cm3, which is only half of steel. It can greatly reduce the equipment load.
4. Convenient construction
[Application]
It is used for coal conveying, material conveying system, pulverizing system, ash discharging and dedusting equipment in thermal power, iron and steel, smelting, machinery, coal, mining, chemical industry, cement, port and wharf industries etc.
[Chemical composition and physical properties]
Series | T36 | TG365 |
AL2O3(%) | 92±0.5 | 95±0.5 |
Bending strength (Mpa) | ≥220 | ≥250 |
Compressive strength (Mpa) | ≥1050 | ≥1300 |
Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 |
Rockwell hardness (HRA) | ≥82 | ≥85 |
Wear volume (cm3) | ≤0.25 | ≤0.2 |
Bulk density (g/cm3) | ≥3.6 | ≥3.65 |
[Specification Available]
Length*Width | Height | Note |
10*10 | 3-10 | paste |
17.5*17.5 | 3-10 | paste |
20*20 | 4-10 | paste |
25*25 | 4-10 | paste |
