WEAR RESISTANT CERAMIC TUBE
Alumina ceramic tube is a very wear-resistant precision ceramic material. Its production process is relatively complicated. The main steps include material selection, molding, sintering, etc. Different shapes and sizes of products require different molding methods. The ceramic products formed by molding and high-temperature sintering have the characteristics of high purity, good density, good wear resistance, corrosion resistance, and low wear. Due to its excellent performance, it can be widely used in various industries.Production process of wear-resistant ceramic tubes.Our tubes are carefully manufactured from special Aluminium ceramic 92 and 95 composition. Using techniques like high-pressure extrusion and isostatic pressing.
Features
1. Alumina ceramic tubes are wear-resistant, ten times more wear-resistant than ordinary pipes under the same conditions.
2. Stable chemical properties, acid, alkali and corrosion resistance.
3. Strong fire resistance and high temperature resistance, working at high temperatures will not affect its performance.
4.The inner and outer walls are smooth, and there will be no blockage or hanging of materials
Easy to install, save manpower, reduce equipment load, and save costs.
Applications
1.Mining industry: used on wear parts such as mills and mine pipes, which can effectively improve the service life and operating efficiency of equipment.
2.Petroleum and chemical industries: suitable for high-temperature pipelines, equipment wear parts, reactors, heating furnaces, catalytic converters, etc. These parts show good corrosion resistance and are difficult to corrode.
3.Electric power and cement industries: used in cement kilns, hot air pipes, coal-fired boilers, fly ash transportation and other equipment, with excellent properties such as high temperature resistance, wear resistance and corrosion resistance.
4.Environmental protection industry: can be used in environmental protection fields such as drinking water pipes and sewage treatment pipes. Due to its non-toxic and environmentally friendly characteristics, it is widely used.
Production process of wear-resistant ceramic tubes
1.Powder calcination: Calcine alumina ore powder according to different formulas to obtain calcined α-alumina powder suitable for production;
2.Powder grinding: Grind the calcined α-alumina powder according to the formula to prepare for ceramic powder suitable for molding. Generally, wet ball milling is used;
3.Powder preparation: High-quality powder suitable for green body molding is obtained by spray granulation;
4.Molding: According to the requirements of product design, the high-quality powder after spray granulation is pressed by dry pressing or isostatic pressing to obtain qualified ceramic blocks or ceramic ring green bodies;
5.Sintering: The process of densification of the pressed green body, generally using an electric kiln;
6.Installation: After the sintered ceramics are inspected and qualified, wear-resistant ceramic tubes are made by gluing, spot welding, lining ceramic rings, etc.
Mineral Processing | |
System | Application |
Material Conveying System | Tailing pipeline |
Concentrate pipeline | |
Backfill mineral | |
Grinding System | Chute and hopper lining |
Outlet pipeline | |
Mineral Processing System | Vibrating chute |
Cyclone | |
Entrifugal dehydrator |
Power Generation | |
System | Application |
Coal-Conveying System | Coal-conveying pipeline |
Belt joint hopper | |
Coal hopper | |
Raw coal hopper | |
Coal feeder | |
Coal Pulverizing System | Coal mill drum |
Chute and hopper lining | |
Outlet pipeline | |
Primary air pipe and elbow | |
Pulverized coal pipe and elbow | |
Bumer pipeline | |
Dust Removing System | Dust removing pipe and elbow |
Fine fly ash pipe | |
Dust Disposing System | Slag removal |
Dry ash pipe |
PHYSICAL PROPERTIES
Series | BM92H | BMG95H | BME95H |
AL2O3 (%) | 92±0.5 | 95±0.5 | 95±0.5 |
Bulk density(g/cm3) | ≥3.6 | ≥3.65 | ≥3.7 |
Compressive strength (MPa) | ≥1050 | ≥1300 | ≥1600 |
Bending strength (MPa) | ≥220 | ≥250 | ≥300 |
Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 | ≥4.0 |
Rockwell hardness (HRA) | ≥82 | ≥85 | ≥88 |
Mohs hardness | 9 | 9 | 9 |
Series | BMZTA | BMZR |
AL2O3 (%) | ≥75 | - |
ZrO2 (%) | ≥21 | 94.8±0.5 |
Bulk density(g/cm3) | ≥4.1 | ≥5.9 |
Compressive strength (MPa) | ≥2000 | - |
Bending strength (MPa) | ≥400 | ≥800 |
Fracture toughness (MPam1/2) | ≥4.5 | ≥7 |
Rockwell hardness (HRA) | ≥90 | ≥88 |
Loss bulk (cm3) | ≤0.05 | ≤0.02 |
Ceramic Tube Dimensions
Outer Diameter | Inside Diameter | Thickness |
φ25 | φ10 | φ7.5 |
φ30 | φ15 | φ7.5 |
φ40 | φ20 | φ10 |
φ50 | φ37 | φ6.5 |
φ65 | φ52 | φ6.5 |
φ80 | φ67 | φ6.5 |
φ100 | φ84 | φ8 |
φ125 | φ109 | φ8 |
φ150 | φ134 | φ8 |
φ200 | φ184 | φ8 |
φ250 | φ230 | φ10 |
FAQ
Q1:What is the packaging method of ceramic tubes?
Wooden case packing.
Q2:Can ceramic tubes be customized?
The thickness and size can be customized.
Q3:.Why choose our ceramic tubes?
Regular size, complete specifications, high purity, good density, good wear resistance, corrosion resistance, good high temperature resistance, low wear, no abrasive pollution.
Q4:What are the main reasons affecting the wear resistance of wear-resistant ceramic rings?
The wear resistance of the lining wear-resistant ceramics, which is mainly determined by the hardness, strength and roughness of the material.
Q5:Where is the nearest port?
Qingdao port
